Wheel Sand Washer
Raw materials:Sand and gravel
Capacity:50-2180t/h
Max feeding size:≤10mm
Application:Aggregate processing system, production line of manufactured sand
XSD Series Bucket Sand Washers are mainly used for washing and dehydrating sand stones for constructions. It is the highly effective equipment that is matched with sand maker.
Technical Parameters:
Model | XS2600 | XS2600 II | XS2800 | XS3200 | XS3600 |
Diameter of The Wheel Bucket(mm) | 2600 | 2600 | 2800 | 3200 | 3600 |
Rotation Rater(r/min) | 2.5 | 2.5 | 1.2 | 1 | 1 |
Maximum Feeding Size(mm) | ≤ 10 | ≤ 10 | ≤ 10 | ≤ 10 | ≤ 10 |
Capacity (t/h) | 20~50 | 30~70 | 50~100 | 80~120 | 120~180 |
Motor Power(kw) | 5.5 | 5.5 | 7.5 | 11 | 15 |
Overall Dimensions (L×W×H)(mm) | 3515×2070×2672 | 3515×2270×2672 | 3900×3300×2990 | 3965×4440×3410 | 4355×4505×3810 |
Weight(kg) | 2500 | 2900 | 3980 | 7270 | 9430 |
Technology Advantages of XSD Series Wheel Sand Washer:
XSD Series Wheel Sand Washers are widely used in gravel plant, mine, building material, transportation, chemical industry, hydropower station, concrete mixing plant and so on for washing and screening materials.
1.Reasonable structure. The impeller drive bearing is isolated from water and materials buried in washer, which greatly avoid the bearing damaged because of soaking in water,sand and other pollutants.
2.Extremely rare lost of medium and fine sand, the grading and fineness module of washed building sand have achieved two national standards" sand for building" and" cobble and gravel for building".
3.Almost no wear parts except for the sieve mesh of sand washer.
4.High output and low power consumption.
5.Longer service life and convenient maintenance.
6.Save water resource.
7.No pollution and high cleaning degree.
