Composite crusher

Category:Crushing Equipment Tag:Composite crusher   Browse Number:

    Composite crusher, also known as vertical compound crusher, is a kind of crushing machine which combining the advantages of impact crushers and hammer crushers.

Composite crusher

    It has the characteristics of high reduction ratio, low power consumption, stable performance and easy maintenance, etc.

Technical parameter of Composite Crusher:

Model
Feed grain
         (mm)
Material-insize
         (mm)
Trening capacity
         (t/h)
Motor power
         (mm)
Maine shaft speed
         (mm)
Overall dimension
         (LxWxH)
         (mm)
PEL-800
100
0-5
10-20
22
934
2100x1200x1700
PEL-1000
120
0-5
20-40
45-55
769
2600x1400x1900
PEL-1250
150
0-5
40-70
75
530
2800x1600x2100
PEL-1500
180
0-5
70-100
90-110
495
3100x1900x2200
PEL-1750
200
0-5
130-190
132-160
424
3710x2360x2390
PEL-2000
220
0-5
200-260
185
370
4100x2660x2620

Note:This is just reference,if you want to know more please contact us to get offer and process.

For different ore, choose different internal structure, we provide customized service!

Composite crusher

Applications of Composite Crusher:

    Our compound crusher is mainly used to crush cement raw materials and cement clinker. It can also be applied to crush iron ore, sandstone, plaster, coal gangue, lump coal, limestone, dolomite, granite, basalt and other stones. Composite crusher is a kind of no screen, adjustable fine crushing machine. It is optimal designed on the basis of advanced fine crushing technology both at home and abroad. It is mainly adapted to medium-sized raw materials and clinkers , at the same time can also be used for fine-crush dolomite, coke precious stones, lead-zinc, serpentine, blast furnace slag, coal gangue , phosphate rock materials with medium hardness , especially suitable for hard limestone, dolomite, granite, basalt artificially build sand or highway pavement stone processing.
